NEW LAUNCH: UNITRACC Module "Details on the Installation of Lining with UV Cured-in-Place Pipes" (Renovation: CIPP)

Nov 09, 2023

Introducing the new e-learning module for the course "Renovation: Lining with Cured-In-Place Pipes"! This module focuses on the installation of UV CIPP using the high-quality SAERTEX-LINER® specifically designed for gravity pipes and sewers - with contributions by renowned manufacturer SAERTEX multiCom GmbH.

Description

The renovation of our aging drainage systems, much like their initial construction, is a task that spans across generations. The methods and regulations for their rehabilitation undergo a continuous process of development and improvement.

The module Details on the Installation of Lining with UV Cured-in-Place Pipes is part of the upcoming course BE-13 Renovation: Lining with Cured-In-Place Pipes (CIPP). This unit focuses on the ordering and installation of the manual SAERTEX-LINER® for gravity pipes and sewers by renowned manufacturer SAERTEX multiCom GmbH. It provides a comprehensive overview of the essential work steps, starting from site preparation to the installation of the lining tube, the curing process, and the necessary final steps.

The course BE-13 offers all the relevant information required to gain a detailed understanding of the lining process, with a specific focus on "in-situ curing hose lining" and "pipe wrapping lining." It covers a wide range of procedures, including their proper configuration, application, and quality assurance.

The e-learning material comprises more than 70 pages, featuring over 150 visual elements such as photographs, tables, illustrations, videos, etc.

The estimated learning time is approximately 4 hours.





Click here to access Details on the Installation of Lining with UV Cured-in-Place Pipes (CIPP)!





Learning Objectives
  • Understanding the process of curing of the lining tube with regard to:
    • logging
    • working pressure
    • positioning of the light source
    • ignition schemes for various UV lamps

  • Knowing requirements for special rehabilitation conditions like:
    • special profiles
    • bends
    • nominal diameter changes

Costs
  • Courses (incl. Certificate): 700 €
  • UNITRACC Knowledge Portal for Enterprises: 150 € p/m


Certificate

Completion certificate for passing course exam of BE-13


Time and Place
  • Distance / remote learning (online)
  • Flexible, extra-professional (part-time, full-time)

Target Group
  • Engineers
  • Technicians
  • Technical staff & executives (e.g., site / construction managers)

Recommended Qualification
B.Eng / B.Sc. or Bachelor Professional's degree with two years of working experience in civil / environmental engineering.

Preview: Renovation - Details on the Installation of UV CIPP with Saertex multicom GmbH Liner [Source: visaplan GmbH]
Content (Selection)
  • Preparation
    • Safety measures
    • Delivery of the lining tube
    • Site preparation (equipment, etc.)

  • Installation
    • Inserting and pulling in the lining tube (e.g., cap protection)
    • Installing the packer
    • Curing
    • Ignition Schemes for UV lamps


  • Final Work
    • Removing packers and UV lamps
    • Removing inner foil
    • Cutting back CIPP liner

  • Special Rehabilitation Conditions
    • Special profiles
    • Bends
    • Nominal diameter changes




UNITRACC Portal for Enterprises

UNITRACC is an e-learning, information, and working platform for underground construction. It has been providing online training courses to customers - who are mainly public agencies, engineering offices, higher education institutions, and skilled individuals - since 2003. The UNITRACC Knowledge Portal for Enterprises offers digital access to all courses, modules, construction site documentations, and technical books about the rehabilitation and maintenance of drains and sewers for a monthly fee of 150 €. Topics include water and wastewater pipeline construction, rehabilitation, management, and maintenance. They cover a huge variety of trenchless construction and rehabilitation technologies such as utility tunneling, microtunneling, pipe bursting, lining with close-fit pipes, lining with continuous pipes, lining with spirally-wound pipes, lining with cured in cured-in-place pipes (CIPP), injection and sealing processes as well as open cut method. Registration is free of charge. Click here to start the booking process.




Let's discover the underground!
