NEW LAUNCH: UNITRACC Module "Application of Coding Systems Using the Example of EN 13508-2"

Oct 17, 2023

New e-learning module of the course BE-07 Investigation and Inspection of Sewers and Pipelines now available on UNITRACC! It covers the application of the coding system EN 13508-2.

Summary of the Module

Investigation is the first of four basic measures in the context of integral urban drainage and sewerage management. It aims to provide the basis for assessing the performance of drain and sewer systems. The results obtained will serve as proof of complying with due diligence obligations and, in particular, as a basis for planning all operations, maintenance, and rehabilitation activities.

The documentation of damages, defects, and other observations in sewers and pipes within the scope of CCTV inspection is not possible without a uniform nomenclature. In Europe, EN 13508 Part 2: Coding system for visual inspection provides the normative basis for documenting and describing various observations, which later serve the engineer as a basis for assessment. This module provides the basic knowledge required for the structure and application of the coding system.

The e-learning material compromises more than 40 pages showing over 50 visual elements such as photographs, tables, and illustrations.

The estimated learning time is approximately 2,5 hours.





Click here to access Application of Coding Systems Using the Example of EN 13508-2!





Learning Goals
  • Understanding the coding system EN 13508-2
  • Differentiating between basic information and findings
  • Identifying coding differences between sewers and manholes
  • Knowing codes for:
    • route finding
    • tightness indication
    • location on the circumference
    • the procedure of inspection in an object

Recommended Qualification
B.Eng / B.Sc. or Bachelor Professional's degree with two years of working experience in civil / environmental engineering.




Costs



  • Courses (incl. Certificate): 700 €
  • UNITRACC Knowledge Portal for Enterprises: 150 € p/m

Time and Place
  • Distance learning (online)
  • Flexible, extra-professional (part-time, full-time)

Target Group
  • Engineers
  • Technicians
  • Technical staff & executives

Certificate

Completion certificate for passing course exam of BE-07



Preview: Module Application of Coding Systems Using the Example of EN 13508-2 [Source: visaplan GmbH]

Content
  • Defects
    • Stresses on Drains and Sewers
    • Defect vs. Damage
    • Causes
    • Sewers and Drains: Introduction

  • Header Information
    • Sewer Section Identification
    • Binding Header Information
    • Master Data

  • Code and Coding Systems
    • General Information
    • Drains / Sewers vs. Manholes
    • Manholes and Inspection Chambers

  • Longitudinal Location
    • Reference Point
    • Continuous Observation

  • Structure of the Main Codes
    • Letters 1-3
    • Characterisation
    • Quantification
    • Circumferential Location
    • Observation at a Pipe Joint
    • Photo / Video Reference
    • Remarks

  • Control Codes
    • Coding Process
    • Examples (e.g., cancellation of the inspection)




UNITRACC Portal for Enterprises

UNITRACC is an e-learning, information, and working platform for underground construction. It has been providing online training courses to customers - who are mainly public agencies, engineering offices, higher education institutions, and skilled individuals - since 2003. The UNITRACC Knowledge Portal for Enterprises offers digital access to all courses, modules, construction site documentations, and technical books about the rehabilitation and maintenance of drains and sewers for a monthly fee of 150 €. Topics include water and wastewater pipeline construction, rehabilitation, management, and maintenance. They cover a huge variety of trenchless construction and rehabilitation technologies such as utility tunneling, microtunneling, pipe bursting, lining with close-fit pipes, lining with continuous pipes, lining with spirally-wound pipes, lining with cured in cured-in-place pipes (CIPP), injection and sealing processes as well as open cut method. Registration is free of charge. Click here to start the booking process.




Let's discover the underground!
